Biological Safety Cabinet AM-ABS-86IIA2 Class II A2

Biological Safety Cabinet AM-ABS-86IIA2 Class II A2

Advantages

  1. Small dimension, save space.
  2. Centrifuge fan, speed adjustable; H14 HEPA filter.
  3. Motorized front window: the front window is motorized for convenient, one-hand operation.
  4. Audio and visual alarm: Abnormal airflow velocity, Filter replacement, Front window at unsafe height, High filter pressure alarm.
  5. Time reserve function: this can save 30 minutes waiting time after activating the cabinet and the sterilization time after experiment.
  6. Remote control: each function can be realized 6 meters away from the cabinet by remote control, which can protect the operator under emergency.
  7. Large LCD display: operators can check detailed status of the cabinet, such as inflow and downflow velocity, work area temperature and humidity, filter pressure, UV working time and filter working time, filter life indicator etc.
  8. With memory function in case of power-failure.
  9. Interlock function: UV lamp and front window; UV lamp and blower, LED lamp; blower and front window.
Category:

MODEL ABS-86IIA2
External Size(W*D*H) 700*650*1230 mm
Internal Size(W*D*H) 600*500*540 mm
Tested Opening Safety height: 200mm (8″)
Max Opening 370 mm (15″)
Inflow Velocity 0.53±0.025 m/s
Down Flow Velocity 0.33±0.025 m/s
HEPA Filter Two, 99.999% efficient at 0.3μm. Filter life indicator.
Front Window Motorized. Two-layer laminated toughened glass ≥5mm. Anti UV.
Noise EN12469 ≤ 58 dB / NSF49 ≤ 61 dB
UV Lamp 15W*1
UV timer, UV life indicator, emission of 253.7 nanometers for most efficient decontamination
LED Lamp 8W*2
Illumination ≥1000Lux
Consumption 500W
Socket Two, total load of two sockets: 500W
Display LCD display
Control System Microprocessor
Airflow System 70% air recirculation, 30% air exhaust
Visual and Audio alarm Filter replacement, window over height, abnormal air flow velocity; High filter pressure alarm
Material Work Zone: 304 stainless steel
Material Main Body: Cold-rolled steel with anti-bacteria powder coating.
Work Surface Height 750mm with optional base stand
Power Supply AC220V±10%, 50/60Hz; 110V±10%,60Hz
Standard Accessory LED lamp, UV lamp*2, Remote control, Waterproof sockets*2
Optional Accessory Base stand, Universal caster with brake and leveling feet, SS Water tap*1, SS Gas tap*1
Gross Weight without Base Stand Carton:100kg
Gross weight with Base Stand Carton:120kg
Package Size without Base Stand Carton body: 760*800*1400mm
Package Size with Base Stand Carton body with base: 800*900*1450mm
