Technical Specifications
| PARAMETER | SPECIFICATION |
| Test project | >70 |
| Wavelength | 450,492,510,546,578,630nm |
| Flow cell | 32uL,quartz glass |
| Liquid volume | 200-3000uL |
| Resolution | 0 .001Abs(display),0.0001Abs(calculation) |
| Carry over | <1% |
| Repeatability | <1% |
| Printer | Internal thermal-sensitive printer, 58mm paper width |
| Display | 240*64 LCD |
| Data communication | RS-232 serial cable |
| Temperature | 10°C-30°C wet≤80% |
| Power supply | 220VAC±15% or 110VAC±15% 50-60Hz 50w |
| Dimension | 380mm(L)*320mm(W)150mm(H) |
| Weight | 5Kg |
| Bolus Volume | Range: 1.0~50.0ml, (0.1ml step) |
Â
Usual test list
| Alanine Aminotransferase | ALT | Serum chlorine | CL |
| Glutamic-oxalacetic transaminase | AST | Inosine anhydride | CRE |
| Alkalinity phosphatase | ALP | Triglyceride | TG |
| Total bilirubin | TBIL | Cholesterol | TCHO |
| Direct bilirubin | DBIL | Glucose | GLU |
| Total protein | TP | Serum potassium | K |
| Albumin | ALB | Serum sodium | Na |
| Urea nitrogen | URE | Serum calcium | Ca |
