Design Features
-It is designed under overall engineering and ergonomic concept. All the components are processed with computer numerical controlled machine
-Specimen retraction function, protects specimen from blade injury
-Trimming/Cutting button makes it easy to switch from trim and section mode
-Equip with counter to calculate total pieces and thickness.
-Dual compressors, which are made in Germany, freeze the cryostat chamber, freezing shelf, knife holder and specimen clamp separate with pro-environment refrigerant R404
-Temperature can drop to working condition in 60 minutes after switching on.
-Adopt to UVC sterilize for 35 minutes every time.
-Peltier may be on or off manually.
-Heated, removable sliding window.
-Two defrost methods: definite time and manual
-The high-precision microtome is enclosed outside the cryostat chamber to protect it from thermal expansion and contraction and keep minimum service and maintenance.
-Self-explanatory symbols for all functions and displays, easy to learn and operate.
-LED screen can display data such as sample travel, thickness, function controlling, day, time, temperature, timed on/off and so on
-Standby mode, after initializing, the temperature in cryostat chamber can be controlled between -4°C and -9°C by computer automatically; When stop initializing, the temperature in freeze chamber will arrive to working temperature within 10 minutes
-Control panel with locking function to avoid wrong operation.
-Hand wheel locking
-Sensor self-diagnosis function.
-Wide freezing shelf may put 10 specimen cassettes
Technical Specifications
-Freeze chamber temperature range: -10°C~-30°C
-Cooling down time to -30°C: 60 min
-Freeze shelf minimum temperature: -45°C
-Lowest temperature of Peltier unit on freeze shelf: -55°C
-Peltier working time: 15 minutes
-Maximum specimen size: 35mm×35mm
-Specimen vertical stroke: 60mm
-Specimen horizontal stroke: 20mm
-Coarse feeding speed: 0.7mm/s; 0.35mm/s
-Section thickness range: 1μm~80μm adjustable; 1μm~20μm, in 1μm increment
20μm~40μm, in 2μm increments; 40μm~80μm, in 5μm increments
-Trimming thickness range: 10μm~400μm adjustable; 10μm~50μm, in 5μm increments; 50μm~100μm, in 10μm increments; 100μm~400μm, in 50μm increments;
-Retraction range: 0μm~80μm adjustable; In 5μm increment
-Voltage and frequency: AC220V±10% 50Hz (Standard) Special requirement may customize by order.
-Power: 850W
-Weight: 130kg
-Dimensions(W×D×H): 660×640×1130mm
