Specifications
Maximum rating
For fluoroscopy:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â 75kVp 3-5mA (uncontinuous use)
Routine fluoroscopy condition: Â 65kVp 3mA
For radiography:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â 75kVp 10mA 6sec, (interval time 3 minutes)
Power supply         Â
AC: Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â 220V, 50Hz,1kVA
Current:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â for fluoroscopy 2A (uncontinuous)
                                for radiography 6A (instantaneous)
Size of screen:Â Â Â Â Â Â Â Â Â Â 203mm X 254mm
Range of movement:Â Â up-down: 220mm, left-right: 130mm,
