Features
- Compatible with any brand syringes from 5ml,10ml,20ml,30ml,50ml and 60ml.
- Stackable to be the maximum 8 channels.
- High accuracy +/- 2% after correct calibrated.
- Five work modes: Rate /Time/Dose/Sequential/Drug library Mode.
- Manual or Automatic Bolus function.
- Vertical & Horizontal mounting clamp.
- Anti-bolus system to reduce significantly after occlusion sudden release.
- DPS Occlusion Pressure display.
- 2000 events stored can be checked and downloaded.
- Large color TFT display with adjustable brightness.
Technical Specifications
| PARAMETER | SPECIFICATION |
| Applicable syringes | 5ml,10ml,20ml,30ml,50ml,60ml of any standard |
| Accuracy | +/- 2% with correct calibration |
| Rate mode | 0.1ml/h-2000.0ml/h (0.1ml/h or 1ml/h step) |
| Time Mode | SOL. VOL:0.1-9999.9ml (0.1ml step) TIME：00:01-99:59min (1min step) |
| Dose Mode: | Volume：0.1-999.9ml(0.1ml step) DRUG MASS：0.1-999.9mg (0.1mg step) DOSE：0.001-9999 (0.001 step) WEIGHT：0.1-300kg(0.1kg step) |
| Total Volume Range | 0.1-9999.9ml (0.1 ml step) |
| Drug library Mode | ASP-1800G with drug library |
| Sequential mode | (Optional) |
| Purge Rate | Programmable and adjustable |
| KVO Rate | 0.0~5.0 ml/h, Programmable and adjustable |
| DPS Occlusion Pressure | LOW:60(±15) kPa, MEDIUM:90(±15) kPa HIGH:120(±15) kPa (Adjustable) |
| Alarms | Loose, Occlusion, Empty, Near Empty, Rate Abnormal, Low Battery, No Battery, Infusion Complete, No Action, Syringe Plunger Disengagement |
| Alarm volume | Three levels: LOW, MEDIUM or HIGH |
| Bolus Rate | 0.1-2000ml/h, Programmable and adjustable, Automatic/Manual bolus available |
| Bolus Volume | Range: 1.0~50.0ml, (0.1ml step) |
| Interface | RS-232 |
| Brightness | 1~10 levels can be selected |
| History records | 2000 events stored can be checked and downloaded |
| Power source | AC power supply: AC 100 to 240V( +/-10%)，50/60Hz;
DC Power supply: 12~15V, power>15W; Built-in Lithium Battery: Rechargeable, 11.1V, 2000mAh. 12 hours of continuous operation |
| Protection Class | Class I, Type CF, IPX4 |
| Dimension / N.W | 240mm*150mm*117mm, 2.5kg |
| Packing size/G.W | 300mm*260mm*160mm, 3.5KG |
