Technical Specifications
| PARAMETER | SPECIFICATION | |
| Display Mode | High-definition 10.4” TFT color LCD screen | |
| Ventilation Mode | VCV, PCV, SIMV, PSV, PSV+SIMV, CPAP, PEEP, SIGH, Standby, IP, IRV | |
| Ventilation Parameters | Tidal Volume | 20~1800 ml |
| Rate | 1~120 bpm | |
| SIMV Rate | 2~20bpm | |
| I:E | 4:1~1:8 | |
| Pressure Trigger Sensitivity | -1.0~2.0kPa | |
| Flow Trigger Sensitivity | 1-20L/min | |
| PEEP | 0~2.0Kpa | |
| Pressure Range | 3~60cmH2O | |
| Pressure Support | 3~60cmH2O | |
| SIGH | 1.5 times the inspiratory time (60-120 adjustable) | |
| Inspiratory Platform | 0~50% | |
| Oxygen Concentration | 21~100% | |
| Pressure Limitation | 5~60cmH2O | |
| Pressure Slope | 1~10 gear | |
| Flow Rate Setting | 1~10 gear | |
| Expiratory Trigger Pressure | -1.0~2.0kPa | |
| Time Control | 1~10s | |
| Parameters for Ventilation Monitoring | Tidal volume, ventilation volume, IPPV rate, SIMV rate, total respiratory rate, I/E, peak pressure of airway, average pressure, pressure – time waveform, flow rate – time waveform,
PEEP, inspiratory trigger pressure, Inspiratory platform (autonomous inspiratory rate, lung compliance, airway resistance, flow -volume loop, pressure-volume loop). |
|
| Monitoring of Oxygen
Concentration |
21%~100% | |
| Power | AC 220V±10% 50Hz±1Hz; UPS, Storage battery | |
| Mechanical Arms | ||
| Air Compressor | ||
| End-expiratory CO2 Monitoring | (Optional Parts) | |
| SECURITY ALARM SYSTEM | ||
| Oxygen Concentration Alarm | Upper Limit Setting Range | 21%~100% |
| Low Limit Setting Range | 10%~80% | |
| Airway Pressure Alarm | Upper Limit Setting Range | 0.3~6.0 kPa |
| Low Limit Setting Range | 0.2~5.0 kPa | |
| Per-minute Ventilation
Volume Alarm |
Upper Limit Setting Range | 3.0~30L/min |
| Low Limit Setting Range | 1.0~10L/min | |
| Respiratory Rate | Upper Limit Setting Range | 50~99bpm |
| Low Limit Setting Range | 0~50bpm | |
| Tidal Volume | Upper Limit Setting Range | 10~2000ml |
| Low Limit Setting Range | 0~1800ml | |
| Sustained High-pressure
Alarm |
It will give alarm when stress have consistently been higher than 2.5kPa. | |
| Suffocation Alarm | It will give sound and light alarm if there is no tidal volume input for 15 seconds. | |
| Power Alarm; Gas Shortage Alarm; Intubation off Alarm |
